002441116

Vaizdas ETITEC A 440/5/B-N

ETITEC A 440/5/B-N Viršįtampių ribotuvas

ETI kodas:: 002441116
Funkcija:: SPD
Tipas:: A
AC max continous operating voltage Uc:: 440 V
Terminal type:: Piercing on both sides
Clamping cross-section (mm²):: 16-95 mm²
In (8/20):: 5 kA
Srovės tipas:: AC
Vardinė įtampa AC (V):: 230 V
Up - Apsaugos lygis (kV):: 1,4 kV
Tinklo tipas:: TN
Nuotėkio srovė:: ✓
Montavimas:: Overhead line protection
Taikoma technologija:: MOV
Katalogo grupė:: ETITEC A

Produktas

EAN code for a single product: 3838895743132
Svoris: 0,2 kg
Stock unit of measure: pcs

Transporto pakuotė

Transport packaging quantity: 28 pcs
EAN code for a transport packaging: 3838895743149
Transport packaging weight: 7,696 kg
Transport Packaging Dimensions Height: 250 mm
Transport Packaging Dimensions Width: 230 mm
Transport Packaging Dimensions Depth: 290 mm
Transport packaging volume: 16,675 dm³
Pallet quantity: 1 652 pcs
Customs tariff: 85363090

System configuration TN-C: ✓
Max. discharge surge current (8/20): 40 kA
Number of conductors (without earthing): 1
Nominal voltage AC: 230 V
Max. conductor cross section solid (solid, stranded): 95 mm²
Mounting method: Direct mounting
Construction size: Other
Short-circuit breaking capacity (Isccr): 4 kA
System configuration TN-S: ✓
Voltage protection level: 1,4 kV
System configuration TN: ✓
Signalling at the device: Optical
Category type 2: ✓
Max. continuous voltage AC: 440 V
Nominal discharge surge current (8/20): 5 kA

ETIM klasifikacija – 9.0 versija
