NHS3L/MS gPV 450A/1500V DC UL Saugikliai

ETI kodas:: 004110732
Tipas:: NH-S
Dydis:: NH3L
Vardinė srovė (A):: 450 A
Charakteristika:: gPV
Indikacija:: Augšējā drošinātāja statusa indikators
Vardinė įtampa DC (V):: 1500 V
Atjungimo geba (DC) (kA):: 50 kA
L/R (ms):: 3 ms
Galios nuostoliai (0,7xIn) (W):: 29 W
Pd (W):: 75 W
Joul`io integralas atjungimas (A2s):: 130 000
Joul`io integralas (A2s):: 600 000
Standartai:: IEC 60269-6, UL 248-19
Pritaikymas:: Fuse link for DC application

Priedai

Produktas

Svoris: 1 980 g
Net width: 73 mm
Net height: 196 mm
Net depth: 87,5 mm
Stock unit of measure: pcs

Pagrindinė pakuotė

Basic packaging quantity: 1 pcs
EAN code for a basic packaging: 3838895868392
Basic packaging weight: 2,04 kg
Basic Packaging Dimensions Height: 0,077 m
Basic Packaging Dimensions Width: 0,224 m
Basic Packaging Dimensions Depth: 0,102 m
Basic packaging volume: 0,002 m³

Transporto pakuotė

Transport packaging quantity: 9 pcs
EAN code for a transport packaging: 3838895868408
Transport packaging weight: 18,71 kg
Transport Packaging Dimensions Height: 0,255 m
Transport Packaging Dimensions Width: 0,295 m
Transport Packaging Dimensions Depth: 0,235 m
Transport packaging volume: 0,018 m³
Pallet quantity: 468 pcs
Customs tariff: 85351000

Rated switching capacity AC: 50 kA
Voltage type: DC
Fuse construction type according to IEC 60269: 3L
Rated voltage AC: 1 500 V
Power loss at rated current: 75 W
Rated switching capacity DC: 50 kA
Type of fuse status indicator: Top fuse status indicator
Rated current: 450 A
Rated voltage DC: 1 500
Utilization category: gPV (photovoltaic protection)
